Aruba AP-587EX Outdoor Access

MFG.PART: R7T34A
Item Condition : Brand New

Earn 3,396 points when you buy me!

Hurry! Other 1 people are watching this product
SKU
Aruba AP-587EX Outdoor Access
Add a Review
Be the first to review this product
Special Price $3,396.81 Regular Price $4,725.00
In stock
Free shipping
could be yours in 1 - 5 days
favorite
Hurry! Other 1 people are watching this product

Aruba 580EX Series APs withstand exposure to extreme high and low temperatures and persistent moisture, are fully sealed to keep out airborne contaminants, and include industrial surge protection. The Aruba 580EX Series offers flexible power and management options to meet the needs of diverse environments and can be deployed using existing mounts. Like all Aruba APs, the Aruba 580EX Series is Wi-Fi 6 certified and backed by a limited lifetime warranty.

Details

Features

Ultimate performance and speed for hazardous environments

Weatherproof and temperature hardened Wi-Fi 6 APs with flexible power options that are purpose built to survive in hazardous locations.

Ruggedized connectivity you can depend on

Built on Wi-Fi 6 standards, these APs are Class 1 Division 2, ATEX Zone 2 and IP66 certified to survive in extreme environments – all backed by Aruba’s limited lifetime warranty.

High Wi-Fi 6 performance for harshest outdoor and hazardous indoor environments

Support for hazardous environments such as oil rigs, industrial manufacturing, and transportation sites.

HazLoc Class 1 Division 2, ATEX Zone 2, and IP66 certified for hazardous locations

Delivers impressive multi-gigabit performance and speed with a maximum aggregate data rate of 2.97 Gbps in extreme weather conditions (-40 to +65˚C).

Automatic role-based access enforcement

Centrally configure and automatically enforce role-based policies across wired and wireless networks using Dynamic Segmentation and Policy Enforcement Firewalls.

High power Bluetooth 5 and 802.15.4/Zigbee

Simplified deployment and management of IoT devices for Industrial IoT and manufacturing environments.

Engaging experiences delivered with automation and security.

Exceptional performance with Wi-Fi 6 that’s ideal for hazardous environments such as oil rigs, industrial manufacturing, and transportation sites.

DESIGNED FOR OUTDOOR FLEXIBILITY

Aruba 580EX Series Outdoor Access Points are weatherproofed and temperature hardened to support hazardous indoor and outdoor environments, including outdoor oil rigs, industrial manufacturing, and transportation sites. With Wi-Fi 6 capabilities, high power Bluetooth and 802.15.4/Zigbee radios, and maximum aggregate throughput of 2.97 Gbps, Aruba 580EX Series APs deliver the speed and reliability needed for demanding Industrial IoT environments.

To support high-performance connectivity in dense mobile and IoT outdoor environments, Aruba 580EX Series APs deliver maximum aggregate on air data rates of 2.97 Gbps and include 5 Gbps Smart Rate Ethernet ports. In addition, dual redundant power/port failover and support for AC ensure high availability with uninterrupted performance.

WI-FI 6 BENEFITS

The 580EX Series APs are based on the Wi-Fi 6/802.11ax standard, which means that Wi-Fi 6 features such as Uplink and Downlink Orthogonal Frequency Division Multiple Access (OFDMA), BSS coloring, Downlink Multi-User MIMO (MUMIMO), and cellular co-location are fully supported making it more efficient and secure.

WI-FI OPTIMIZATION

Aruba’s patented AI-powered ClientMatch technology eliminates sticky client issues by steering a client to the AP where it receives the best radio signal. ClientMatch also dynamically steers traffic to load balance APs to improve the user experience.

Tech Specs

Tech specs

HARDWARE VARIANTS

AP-587EXBuilt in 90°H x 90°V directional antennas (H and V polarized)
5Ghz Antennas 5.2dBi uncorrelated avg (6.6dBi peak)
2.4Ghz Antennas 5.7dBi uncorrelated avg (5.8dBi peak)
Bluetooth Antenna 6.3dBi peak

WI-FI RADIO SPECIFICATIONS

AP typeOutdoor Hardened, Wi-Fi 6 dual radio, 5GHz and 2.4GHz 802.11ax 4x4 MIMO
2.4GHz radioFour spatial stream Single User (SU) MIMO for up to 1,150Mbps wireless data rate with individual 4SS HE40 802.11ax client devices or with two 2SS HE40 802.11ax MU-MIMO capable client devices simultaneously
5GHz radioFour spatial stream Single User (SU) MIMO for up to 2.4Gbps wireless data rate with individual 4SS HE80 (or 2SS HE160) 802.11ax client devices, or with four 1SS or two 2SS HE80 802.11ax MU-MIMO capable client devices simultaneously
Supported frequency bands2.400 to 2.4835GHz
5.150 to 5.250GHz
5.250 to 5.350GHz
5.470 to 5.725GHz
5.725 to 5.850GHz
Available bands and channelsDependent on configured regulatory domain
Supported radio technologies802.11b: Direct-sequence spread-spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 37 resource units (for an 80MHz channel)

MECHANICAL SPECIFICATIONS

Dimensions/weight (AP-587 unit only)302mm (W) x 300mm (D) x 174mm (H) / 11.9” (W) x 11.8” (D) x 6.9” (H)
4.51kg / 9.9lbs

Dimensions/weight (AP-587EX shipping pkg, no mount)		385mm (W) x 272mm (D) x 433mm (H) / 15.2” (W) x 10.7” (D) x 17” (H)
6.03kg / 13.3lbs

ENVIRONMENTAL SPECIFICATIONS

Operating conditionsTemperature: -40°C to +65°C / -40°F to +149°F with full solar loading
Humidity: 5% to 93% non-condensing internal
Rated for operation in all weather conditions
Storage conditionsTemperature: -40°C to +70°C / -40°F to +158°F
Operating Altitude3,000 m

ADDITIONAL INTERFACES

Wired network interface (E0)100/1000/2500/5000Base-T Ethernet
5Gbps Smart Rate: NBase-T, 802.3bz
PoE PD support on E0
IEEE/802.3az support
Support for jumbo frames (MTU up to 9,216 bytes)
Wired network interface (E1)10GBASE-R SFP+ port
IEEE/802.3az support (as applicable)
Support for jumbo frames (up to 9,216 bytes)
1 x SFP+ cage
When used in operation it is expected that this is the primary uplink port
Only recommended industrial temperature SFP/SFP+ modules should be used for optimal performance

REGULATORY COMPLIANCE

FCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 60950-1
IEC 60950-22
UL/IEC/EN 62368-1
IEC/EN60601-1-2
EN 50155
EN IEC 60079-0
EN IEC 60079-7
IEC 60079-0
IEC 60079-7
CSA C22.2 No.213-17
UL 121201
UL 50E
For more country-specific regulatory information and approvals, please see your Aruba representative.

CERTIFICATIONS

Wi-Fi Alliance
Bluetooth SIG
Ethernet Alliance (E0, PoE PD device, class 6; E2, PoE PSE device, class 3)

MINIMUM SOFTWARE VERSIONS

ArubaOS and Aruba InstantOS 8.10.0.0
Models

Access Points

Ordering Information

Aruba 580EX Series ordering information

Part Number Description

R7T29AAruba AP-585EX (US) TAA Dual Radio 4x4:4 802.11ax Internal Omni Antennas Unified HazLoc AP
R7T30AAruba AP-585EX (RW) TAA Dual Radio 4x4:4 802.11ax Internal Omni Antennas Unified HazLoc AP
R7T31AAruba AP-585EX (EG) TAA Dual Radio 4x4:4 802.11ax Internal Omni Antennas Unified HazLoc AP
R7T32AAruba AP-585EX (IL) TAA Dual Radio 4x4:4 802.11ax Internal Omni Antennas Unified HazLoc AP
R7T33AAruba AP-585EX (JP) TAA Dual Radio 4x4:4 802.11ax Internal Omni Antennas Unified HazLoc AP
R7T34AAruba AP-587EX (US) TAA Dual Radio 4x4:4 802.11ax Internal Directional Antennas Unified HazLoc AP
R7T35AAruba AP-587EX (RW) TAA Dual Radio 4x4:4 802.11ax Internal Directional Antennas Unified HazLoc AP
R7T36AAruba AP-587EX (EG) TAA Dual Radio 4x4:4 802.11ax Internal Directional Antennas Unified HazLoc AP
R7T37AAruba AP-587EX (IL) TAA Dual Radio 4x4:4 802.11ax Internal Directional Antennas Unified HazLoc AP
R7T38AAruba AP-587EX (JP) TAA Dual Radio 4x4:4 802.11ax Internal Directional Antennas Unified HazLoc AP

Mounting Kits

JW052AAP-270-MNT-V1 AP-270 Series Outdoor Pole/Wall Long Mount Kit
JW054AAP-270-MNT-H1 AP-270 Series Outdoor AP Hanging or Tilt Install Mount Kit
JW055AAP-270-MNT-H2 AP-270 Series Access Flush Wall or Ceiling Mount
R6W11AAP-270-MNT-H3 AP-270 Series Outdoor AP Hanging or Dual-Tilt Install Mount Kit

Power accessories

R1C73AAP-POE-BTSR 1-Port Smart Rate 802.3bt 60W Indoor Midspan Injector
R7T40APD-9501-5GCO-AC 60W 802.3bt Smart Rate Outdoor Surge Protection Midspan Injector
R7T41APD-9501-5GCO-DC 60W 802.3bt Smart Rate Outdoor Surge Protection Midspan Injector

Other accessories

R2X45AAruba AP-USB-ZB External USB based Dongle with Zigbee and BLE for AP
R2Y09AAruba AP-USB-ZB 10-pk External USB based Dongle with Zigbee and BLE for AP
R2Y10AAruba AP-USB-ZB 50-pk External USB based Dongle with Zigbee and BLE for AP
