Aruba 605R Hospitality

MFG.PART: R8N10A#ABA
Item Condition : Brand New

Earn 999 points when you buy me!

Hurry! Other 1 people are watching this product
SKU
Aruba 605R Hospitality
Add a Review
Be the first to review this product
Special Price $999.99 Regular Price $1,495.00
In stock
Free shipping
could be yours in 1 - 5 days
favorite
Hurry! Other 1 people are watching this product

HPE Aruba Networking 600R Series Remote Access Points enable IT teams to deliver a seamless and secure user experience to remote workers and small branch environments. The remote access points are based on Wi‑Fi 6E, achieving a combined maximum 3.6 Gbps data rate (using 5 GHz and 6 GHz bands) and increasing capacity by up to 1200 MHz with more 160 MHz channels to better support ever‑increasing Wi‑Fi demands, especially for latency‑ sensitive, high‑bandwidth video communications.

Details

Features

The new 600R Series APs leverage AOS 10 to provide fast, resilient, and secure Wi-Fi 6E connectivity for mission-critical work.

6 GHz support

Maximum combined 3.6 Gbps data rate for higher throughput and faster speeds indoors (when using 5 GHz and 6 GHz bands).

Configurable dual radios

Support any two of three Wi-Fi 6E bands (2.4, 5, and 6 GHz) and provide full Wi-Fi 6E coverage in a multi-AP environment.

Multiple uplink/downlink options

2.5 Gbps uplink/downlink Ethernet port, dedicated 1 Gbps uplink port, and three dedicated downlink ports to eliminate bottlenecks.

Application Assurance
By allocating radio resources such as time, frequency, and spatial stream to specific traffic types, the APs can provide SLA-grade performance to client devices whether they support Wi-Fi 6E or prior standards. Air Slice relies on the Policy Enforcement Firewall and Deep Packet Inspection (DPI) to identify user roles and applications so bandwidth can be dynamically allocated to ensure performance.

RF optimization
ML-based radio frequency optimization known as AirMatch dynamically adjusts resources such as power to optimize coverage and eliminate coverage gaps.

Advanced Cellular Coexistence
Built-in filtering automatically minimizes the impact of interference from cellular networks, distributed antenna systems (DAS), and commercial small cell or femtocell equipment.

Indoor Location Aware
HPE Aruba Networking 600R Series Remote Access Points include embedded GPS receivers and fine time measurement to accurately auto-locate themselves. They also support Open Locate, an emerging standard that allows APs to share their location over the air and through cloud-based APIs.



Tech Specs

Tech specs

HARDWARE VARIANTS

AP-605RRemote AP platform (desk mount, wired + wireless access), integrated antennas

WI-FI RADIO SPECIFICATIONS

AP typeIndoor, tri-radio, 2.4GHz, 5GHz and 6GHz (dual concurrent) 802.11ax 2x2 MIMO
2.4GHz radioTwo spatial stream Single User (SU) MIMO for up to 574Mbps wireless data rate with 2SS HE40 802.11ax client devices (287Mbps for HE20)
5GHz radioTwo spatial stream Single User (SU) MIMO for up to 1.2Gbps wireless data rate with 2SS HE80 802.11ax client devices
Supported frequency bands2.400 to 2.4835GHz ISM
5.150 to 5.250GHz U-NII-1
5.250 to 5.350GHz U-NII-2A
5.470 to 5.725GHz U-NII-2C
5.725 to 5.850GHz U-NII-3/ISM
5.850 to 5.895GHz U-NII-4
5.925 to 6.425GHz U-NII-5
6.425 to 6.525GHz U-NII-6
6.525 to 6.875GHz U-NII-7
6.875 to 7.125GHz U-NII-8
Supported radio technologies802.11b: Direct-sequence spread-spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 8 resource units

MECHANICAL SPECIFICATIONS



ENVIRONMENTAL SPECIFICATIONS

Operating conditionsTemperature: 0C to +40C / +32F to +104F
Relative humidity: 5% to 95%
Storage conditionsTemperature: -25C to +55C / +13F to +131F
Relative humidity: 10% to 100%
Transportation conditionsTemperature: -40C to +70C / -40F to +158F
Relative humidity: up to 95%

POWER SOURCES AND POWER CONSUMPTION

Power SourcesThe AP ships with a compatible 48V/5W DC power adapter
Maximum (worst-case) power consumption40W
Maximum (worst-case) power consumption in idle mode4.9W

REGULATORY COMPLIANCE

Regulatory complianceFCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
UL/IEC/EN 60950
IEC/EN 62368-1
EN 60601-1-1, EN60601-1-2
For more country-specific regulatory information and approvals, please see your HPE Aruba Networking representative.

CERTIFICATIONS

Wi-Fi AllianceWi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6E (ax, 6GHz)
WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, Wi-Fi Agile Multiband
Passpoint (release 2)

MINIMUM SOFTWARE VERSIONS

Requires HPE Aruba Networking Central 2.5.7 AP license and ArubaOS 10.5.0.0.
Models

Access Points

Ordering Information

Aruba 605R ordering information

Part Number Description

R8N06AHPE Aruba Networking AP-605R-EG Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N07AHPE Aruba Networking AP-605R-IL Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N08AHPE Aruba Networking AP-605R-JP Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N09AHPE Aruba Networking AP-605R-RW Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N10AHPE Aruba Networking AP-605R-US Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N11AHPE Aruba Networking AP-605R-EGF1 TAA Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N12AHPE Aruba Networking AP-605R-ILF1 TAA Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N13AHPE Aruba Networking AP-605R-JPF1 TAA Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N14AHPE Aruba Networking AP-605R-RWF1 TAA Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
R8N15AHPE Aruba Networking AP-605R-USF1 TAA Dual-radio Tri-band 2x2 Wi-Fi 6E Remote Access Point
