Aruba AP-505H Hospitality Wireless Access Point

Aruba AP-505H Hospitality Wireless Access Point

From
Special Price $620.50 Regular Price $944.00
compare favorite favorite
  • Home
  • Aruba AP-505H Hospitality Wireless Access Point
Aruba AP-505H Hospitality Wireless Access Point
Aruba AP-505H Hospitality Wireless Access Point
Aruba AP-505H Hospitality Wireless Access Point
Sale
See all specs
Have questions about this purchase?
Chat with Uvation Assistant
Rewards Banner

Aruba AP-505H Hospitality Wireless Access Point

MFG.PART: R3V48A
Item Condition : Brand New

Earn 620 points when you buy me!

Hurry! Other 1 people are watching this product
SKU
Aruba AP-505H Hospitality Wireless Access Point
Add a Review
Be the first to review this product
Special Price $620.50 Regular Price $944.00
In stock
Free shipping
could be yours in 1 - 5 days
favorite
Hurry! Other 1 people are watching this product
These economical Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing mobile, cloud and IoT requirements. With a wireless aggregate data rate of up to 1.5 Gbps and gigabit local wired ports, they deliver the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike.
Details

Features

High performance, cost-effective Wi-Fi 6 (802.11ax) APs for hospitality, branch offices, and teleworker deployments.

High performance at scale

High-performance, wired and wireless connectivity for any organization experiencing growing mobile, cloud, and IoT requirements in medium-density environments.

Ultimate efficiency

Built on Wi-Fi 6 standards, 500H Series APs include features such as OFDMA, MU-MIMO, and Target Wake Time for better multi-user performance and improved efficiency.

Groundbreaking wireless capabilities

Product features support wired and wireless connectivity (in a single device) from hotels, branch offices, or teleworker initiatives for up to 1.5 Gbps of maximum wireless throughput and 256 associated clients per Wi-Fi radio. USB port for cellular backhaul or IoT expansion (505H).

Best-in-class hardware

Up to four ports for local wired connectivity, PoE out support on up to two ports (505H), and crypto performance of up to 500 Mbps.

WPA3 and Enhanced Open security

Increases enterprise-level security without increasing complexity, and ensures stronger guest access protections.

Engaging experiences delivered with automation and security.

INCREDIBLE EFFICIENCY

The 500H Series APs are designed to optimize user experience by maximizing Wi-Fi efficiency and dramatically reducing airtime contention between clients.

Features include Orthogonal frequency-division multiple access (OFDMA), and cellular optimization. With up to 2 spatial streams (2SS) and 80MHz channel bandwidth, the 500H Series provides groundbreaking wireless capabilities for budget-conscious deployments.

Advantages of OFDMA

This capability allows Aruba’s APs to handle multiple Wi-Fi 6 capable clients on each channel simultaneously, regardless of device or traffic type. Channel utilization is optimized

by handling each transaction via smaller sub-carriers or resource units (RUs), which means that clients are sharing a channel and not competing for airtime and bandwidth.

Advanced Cellular Coexistence (ACC)

This feature uses built-in filtering to automatically minimize the impact of interference from cellular networks, distributed antenna systems (DAS), and commercial small cell or femtocell equipment.

Intelligent Power Monitoring (IPM)

Aruba APs continuously monitor and report hardware energy consumption. They can also be configured to enable or disable capabilities based on available PoE power – ideal when wired switches have exhausted their power budget (AP-505H).

Tech Specs

Tech specs

HARDWARE VARIANTS

AP-505HHigh-end dual radio Wi-Fi 6 Hospitality AP with 1+4 Ethernet ports, PSE, USB

WI-FI RADIO SPECIFICATIONS

AP typeIndoor, dual radio, 5GHz and 2.4GHz 802.11ax 2x2 MIMO
2.4GHz radioTwo spatial stream (SU/MU) MIMO for up to 287Mbps wireless data rate (HE20)
5GHz radioTwo spatial stream (SU/MU) MIMO for up to 1.2Gbps wireless data rate (HE80)
Supported frequency bands2.400 to 2.4835GHz ISM
5.150 to 5.250GHz U-NII-1
5.250 to 5.350GHz U-NII-2A
5.470 to 5.725GHz U-NII-2C
5.725 to 5.850GHz U-NII-3/ISM
5.850 to 5.895GHz U-NII-4
Maximum number of BSSIDs16 BSSIDs per radio
Supported radio technologies802.11b: Direct-sequence spread-spectrum (DSSS)
802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM)
802.11ax: Orthogonal frequency-division multiple access (OFDMA) with up to 8 resource units

MECHANICAL SPECIFICATIONS

Dimensions/weight (AP-505H; unit without mount bracket)

86mm (W) x 47mm (D) x 150mm (H)

Weight: 360g

ENVIRONMENTAL SPECIFICATIONS

Operating conditionsTemperature: 0°C to +40°C / 32°F to +104°F
Humidity: 5% to 93% non-condensing
ETS 300 019 class 3.2 environments
Storage conditionsTemperature: -40°C to +70°C / -40°F to +158°F
Humidity: 5% to 93% non-condensing
ETS 300 019 classes 1.2 and 2.3 environments

POWER SOURCES AND POWER CONSUMPTION

Power SourcesThe AP supports direct DC power and Power over Ethernet
When both DC and PoE power sources are available, DC power takes priority over PoE
Power sources are sold separately; see the 500H Series Ordering Guide for details
Maximum (worst-case) power consumptionDC powered: 14W
POE powered (802.3af): 10.0W
Maximum (worst-case) power consumption in idle mode4.5W

REGULATORY COMPLIANCE

Regulatory complianceFCC/ISED
CE Marked
RED Directive 2014/53/EU
EMC Directive 2014/30/EU
Low Voltage Directive 2014/35/EU
IEC/EN 60950
EN 60601-1-1, EN60601-1-2
IEC/EN 62368-1
For more and country-specific regulatory information and approvals, please see your Aruba representative.

CERTIFICATIONS

Wi-Fi AllianceWi-Fi CERTIFIED a, b, g, n, ac
Wi-Fi CERTIFIED 6 (ax)
WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open (OWE)
WMM, WMM-PS, Wi-Fi Vantage, Wi-Fi Agile Multiband
Passpoint (release 2)

MINIMUM SOFTWARE VERSIONS

ArubaOS and Aruba InstantOS 8.7.0.0 (AP-505H)
Models

Access Points

Ordering Information

Aruba 500H Series ordering information

Part Number Description

R3V44AAruba AP-503H (EG) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+2 Ethernet
R3V42AAruba AP-503H (IL) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+2 Ethernet
R3V40AAruba AP-503H (JP) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+2 Ethernet
R3V36AAruba AP-503H (RW) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+2 Ethernet
R3V38AAruba AP-503H (US) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+2 Ethernet
R7G96AAruba AP-503HR (EU) Remote AP bundle with AP-503H (RW) + desk mount + power adapter + EU power cord
R7G97AAruba AP-503HR (US) Remote AP bundle with AP-503H (US) + desk mount + power adapter + NA power cord
R3V54AAruba AP-503HR (US) Remote AP bundle with AP-503H (US) + desk mount + power adapter + NA power cord
R3V52AAruba AP-505H (IL) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+4 Ethernet, PSE, USB
R3V50AAruba AP-505H (IL) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+4 Ethernet, PSE, USB
R3V46AAruba AP-505H (RW) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+4 Ethernet, PSE, USB
R3V48AAruba AP-505H (US) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+4 Ethernet, PSE, USB
R3V56AAruba AP-505H (US) Dual-radio 802.11ax 2x2 Unified Hospitality AP with 1+4 Ethernet, PSE, USB
R3V57AAruba AP-505HR (US) Remote AP bundle with AP-505H (US) + desk mount + power adapter + NA power cord

Mounting Kits

R3V58AAP-500H-MNT1 Kit with Single-gang Wall-box Mount Adapter for 500H Series AP
R3V61AAP-503H-MNT2 Kit with Dual-gang Wall-box Mount Adapter for AP-503H
R3V59AAP-505H-MNT2 Kit with Dual-gang Wall-box Mount Adapter for AP-505H
R3V60AAP-500H-MNTD Kit with Desk Mount Adapter for 500H Series AP

Power accessories

R3K00AAP-AC2-12B 12V/48W AC/DC desktop style power adapter with 2.1/5.5mm connector
R3K01AAP-AC2-48C 48V/50W AC/DC desktop style power adapter with 1.35/3.5mm connector
R6P68AAP-POE-AFGE 1-Port GbE 802.3af 15.4W midspan injector
R6P67AAP-POE-ATSR 1-Port Smart Rate 802.3at 30W midspan injector
R1C73AAP-POE-BTSR 1-Port Smart Rate 802.3bt 60W midspan injector

Other accessories

R8F89AAruba AP-MC-SFP Media Converter Module for WLAN Access Points (SFP with DC to Copper with POE)
JY728AAP-CBL-SERU Micro-USB TTL3.3V to USB2.0 AP Console Adapter Cable
R6Q99AAP-MOD-SERU Micro-USB TTL3.3V to RJ45 RS232 AP Console Adapter Module
JW072AAP-CBL-ETH10 10-pk Short Ethernet Cable
