This high-performance access point is perfect for high-density mobile and IoT environments.
Able to survive in harsh outdoor environments, the 370 Series APs can withstand exposure to high and low temperature extremes, wind speeds up to 165 mph, tolerate persistent moisture, precipitation, and dust and salt sprays for extended periods. Additionally, all electrical interfaces include industrial-strength surge protection.
The 370 Series APs deliver multi-gigabit Wi-Fi to outdoor and environmentally challenging locations.
With a maximum aggregate data rate of over 2 Gbps, the Wi-Fi 370 Series comes with MU-MIMO, four spatial streams, and optional 160MHz to add performance and capacity.
Extends the temperature range capabilities of indoor access points for environments that lack heating and cooling. The 370 Series APs also provide sealed connector interfaces to protect against dust and moisture.
With a maximum aggregate data rate of over 2 Gbps (2.4GHz: 300Mbps; 5GHz: 1,733 Mbps), the 370 Series comes with multi-user MIMO (MU-MIMO), 4 spatial streams (4SS), and optional 160MHz channel bandwidth (VHT160) to quickly add performance and capacity to existing or new wireless networks.
Able to survive in harsh outdoor environments, the 370 Series can withstand exposure to high and low temperature extremes, windspeeds up to 165 mph, and tolerate persistent moisture, precipitation, and dust and salt sprays for extended periods of time. All electrical interfaces include industrial strength surge protection.
The 370 Series includes Aruba’s patented ClientMatch technology to eliminate sticky client issues while optimizing 802.11ac Wave 2 performance. These APs continuously gather session performance metrics to steer mobile devices to the best-available AP - even while users roam. With MUMIMO awareness, ClientMatch can group MU-MIMO capable devices together to increase network capacity and efficiency. ClientMatch also participates in Aruba’s AI-powered Mobility solution.
The 370 Series includes an integrated Bluetooth Low Energy radio to simplify the deployment and management of location services, asset tracking services, security solutions and IoT sensors. This allows organizations to leverage the 360 Series as an IoT platform, which eliminates the need for an overlay infrastructure and additional IT resources.
| AP-375 | 5 GHz 802.11ac 4x4 MU-MIMO (1,733 Mbps max rate) 2.4 GHz 802.11n 2x2 MIMO (300 Mbps max rate) radios |
| AP type | Outdoor hardened, dual radio, 5 GHz 802.11ac 4x4 MIMO and 2.4 GHz 802.11n 2x2 MIMO |
| 2.4GHz radio | Two spatial stream Single User (SU) MIMO for up to 300 Mbps wireless data rate to individual 2x2 HT40 client devices |
| 5GHz radio | Four spatial stream Multi User (MU) MIMO for up to 1,733 Mbps wireless data rate to up to three MU-MIMO capable client devices simultaneously Four spatial stream Single User (SU) MIMO for up to 1,733 Mbps wireless data rate to individual 4x4 VHT80 or 2x2 VHT160 client devices |
| Supported frequency bands | 2.400 to 2.4835 GHz 5.150 to 5.250 GHz 5.250 to 5.350 GHz 5.470 to 5.725 GHz 5.725 to 5.850 GH |
| Available bands and channels | Dependent on configured regulatory domain |
| Supported radio technologies | 802.11b: Direct-sequence spread-spectrum (DSSS) 802.11a/g/n/ac: Orthogonal frequency-division multiplexing (OFDM) |
| Dimensions/weight (AP-375; excluding mount) | 23 cm (W) x 24 cm (D) x 14 cm (H) 9.0" (W) x 10.6" (D) x 5.5" (H) 2.4 kg / 5.3 lbs |
| Operating conditions | Temperature: -40° C to +65° C (-40° F to +149° F) Humidity: 5% to 95% non-condensing |
| Storage conditions | Temperature: -40° C to +70° C (-40° F to +158° F) |
| Operating Altitude | 3,000 m |
| Wired network interface (E0) | One 10/100/1000BASE-T Ethernet network interfaces (RJ-45) Auto-sensing link speed and MDI/MDX 802.3az Energy Efficient Ethernet (EEE) |
| FCC/ISED CE Marked RED Directive 2014/53/EU EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU UL/IEC/EN 60950 IEC/EN 62368-1 EN 60601-1-1, EN60601-1-2 For more country-specific regulatory information and approvals, please see your Aruba representative. |
| CB Scheme Safety, cTUVus UL2043 plenum rating Wi-Fi Alliance certified 802.11a/b/g/n Wi-Fi CERTIFIED™ ac (with wave 2 features) EN50155 Railway |
| ArubaOS & Aruba InstantOS 8.3.0.0 |
| JZ162A | Aruba AP-374 (RW) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xNf Connectors Outdoor AP |
| JZ163A | Aruba AP-374 (US) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xNf Connectors Outdoor AP |
| JZ159A | Aruba AP-374 (EG) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xNf Connectors Outdoor AP |
| JZ160A | Aruba AP-374 (IL) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xNf Connectors Outdoor AP |
| JZ161A | Aruba AP-374 (JP) 802.11n/ac Dual 2x2:2/4x4:4 Radio 6xNf Connectors Outdoor AP |
| JZ172A | Aruba AP-375 (RW) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Omni Antenna Outdoor AP |
| JZ173A | Aruba AP-375 (US) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Omni Antenna Outdoor AP |
| JZ169A | Aruba AP-375 (EG) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Omni Antenna Outdoor AP |
| JZ170A | Aruba AP-375 (EG) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Omni Antenna Outdoor AP |
| JZ171A | Aruba AP-375 (EG) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Omni Antenna Outdoor AP |
| JZ182A | Aruba AP-377 (RW) 802.11n/ac Dual 2x2:2/4x4:4 Radio Integrated Directional Antenna Outdoor AP |
| JW053A | AP-270-MNT-V2 AP-270 Series Outdoor Pole/Wall Short Mount Kit |
| JW054A | AP-270-MNT-H1 AP-270 Series Outdoor AP Hanging or Tilt Install Mount Kit |
| JW055A | AP-270-MNT-H2 AP-270 Series Access Flush Wall or Ceiling Mount |
| R6W11A | AP-270-MNT-H3 AP-270 Series Outdoor AP Hanging or Dual-Tilt Install Mount Kit |
| R6P67A | AP-POE-ATSR 1-Port Smart Rate 802.3at 30W Indoor Midspan Injector |
| JW629A | PD-9001GR-AC 30W 802.3at PoE+ 10/100/1000 Ethernet Indoor Rated Midspan Injector |
| JW630A | PD-9001GO-DC 30W 802.3at PoE+ 10/100/1000 12-24V DC in Outdoor Surge Prot Midspan Injector |
| JW700A | PD-9001GO-NA 30W 802.3at PoE+ 10/100/1000 Outdoor Surge Prot NA Power Cord Mdspan Injector |
| JW701A | PD-9001GO-INTL 30W 802.3at PoE+ 10/100/1000 Outdoor Surge Prot Intl Power Cord Injector |
| R7T40A | PD-9501-5GCO-AC 60W 802.3bt Smart Rate Outdoor Surge Protection Midspan Injector |
| R7T41A | PD-9501-5GCO-DC 60W 802.3bt Smart Rate Outdoor Surge Protection Midspan Injector |
| Q8N47A | Outdoor AP Covers and Glands 1-pk M25/5-pk M20 Cover/2-pk M16 Cover/5-pk M20 Gland/2-pk Ground Kit |
| Q8N48A | Outdoor AP Metric to Standard M20 to 1/2 inch NPT 5-pk Thread Adapter |
