Base | PowerEdge R550 Server |
Front Storage | Chassis with up to 8x3.5" Drives |
BackPlane | SAS/SATA Backplane |
Trusted Platform Module | Trusted Platform Module 2.0 V3 |
Chassis | 3.5" Chassis with up to 8 Hard Drives (SAS/SATA), 1 CPU |
Processor | Intel® Xeon® Silver 4309Y 2.8G, 8C/16T, 10.4GT/s, 12M Cache, Turbo, HT (105W) DDR4-2666 |
Additional Processor | No Additional Processor |
Processor Thermal Configuration | Standard Heatsink for 1 CPU configuration |
Memory Configuration Type | Performance Optimized |
Memory DIMM Type and Speed | 3200MT/s RDIMMs |
Form Factor | 2U Rack Server |
Memory | 16GB RDIMM, 3200MT/s, Dual Rank |
RAID | C1, No RAID for HDDs/SSDs (Mixed Drive Types Allowed) |
RAID Internal Storage Controllers | Front PERC H355 Front Load |
Storage | 2TB Hard Drive SATA 6Gbps 7.2K 512n 3.5in Hot-Plug |
BIOS and Advanced System Configuration Settings | Power Saving Dell Active Power Controller |
Advanced System Configurations | No Energy Star |
Fans | Standard Fan Cold Swap 2U,V2 x5 |
Power Supply | Single, Hot-Plug, Power Supply (1+0), 600W |
Power Cords | NEMA 5-15P to C13 Wall Plug, 125 Volt, 15 AMP, 10 Feet (3m), Power Cord, North America |
PCLe Riser | 1 CPU, 1x16 LP+ 1x8(x4 link) LP |
OCP 3.0 Network Adapters | No OCP 3.0 mezzanine NIC card, Blank Filler Only |
Bezel | No Bezel |
Boot Optimized Storage Cards | No BOSS Card |
Operating System | No Operating System |
OS Media Kits | No Media Required |
Embedded Systems Management | iDRAC9, Basic 15G |
Quick Sync | No Quick Sync |
Password | iDRAC,Factory Generated Password |
IDRAC Service Module | iDRAC Service Module (ISM), NOT Installed |
Group Manager | iDRAC Group Manger, Disabled |
Rack Rails | No Rack Rails or Cable Management Arm |
