Base | PowerEdge R6525 Server |
Front Storage | Chassis with up to 8x2.5" Drives |
BackPlane | SAS/SATA Backplane |
Trusted Platform Module | No Trusted Platform Module |
Chassis | Chassis with up to 8 x 2.5" Hot Plug Hard Drives (1CPU, No XGMI) |
Processor | AMD EPYC 7443P 2.85GHz, 24C/48T, 128M Cache (200W) DDR4-3200 |
Additional Processor | No Additional Processor |
Processor Thermal Configuration | Heatsink for 1 CPU configuration (CPU greater than or equal to 180W) |
Memory Configuration Type | Performance Optimized |
Memory DIMM Type and Speed | 3200MT/s RDIMMs |
Form Factor | 1U Rack Server |
Memory | 16GB RDIMM, 3200MT/s, Dual Rank |
RAID | C1, No RAID for HDDs/SSDs (Mixed Drive Types Allowed) |
RAID Internal Storage Controllers | Front HBA355 Front Load (for Chassis up to 4 or 8 drives) |
Storage | 480GB SSD SATA Read Intensive 6Gbps 512 2.5in Hot-plug AG Drive, 1 DWPD |
BIOS and Advanced System Configuration Settings | Performance BIOS Setting |
Advanced System Configurations | UEFI BIOS Boot Mode with GPT Partition |
Advanced System Configurations | No Energy Star |
Fans | High Performance Fan for CPU greater than or equal to 180W (1 CPU) |
Power Supply | Single, Hot-plug, Power Supply Non-Redundant (1+0), 800W, Mixed Mode, NAF |
Power Cords | NEMA 5-15P to C13 Wall Plug, 125 Volt, 15 AMP, 10 Feet (3m), Power Cord, North America |
PCLe Riser | Riser Config 8, 1 x 16 Gen4 FH PCIe slot |
Motherboard | PowerEdge R6525 Motherboard, with 2 x 1Gb Onboard LOM (BCM5720)MLK V2 |
OCP 3.0 Network Adapters | No OCP 3.0 mezzanine NIC card, Blank Filler Only |
Bezel | No Bezel for x8 and x10 chassis |
Boot Optimized Storage Cards | None |
Operating System | No Operating System |
OS Media Kits | No Media Required |
Embedded Management Systems | iDRAC9, Express 15G |
Quick Sync | No Quick Sync |
Password | iDRAC,Factory Generated Password |
IDRAC Service Module | iDRAC Service Module (ISM), NOT Installed |
Group Manager | None |
Rack Rails | No Rack Rails or Cable Management Arm or Strain Relief Bar |
