Base | PowerEdge R6625 Server |
Front Storage | Chassis with up to 10x2.5" Drives |
BackPlane | SAS/SATA Backplane |
Trusted Platform Module | No Trusted Platform Module |
Chassis | 2.5" Chassis with up to 10 SAS4/SATA Drives, Front PERC 11 |
Processor | AMD EPYC 9224 2.50GHz, 24C/48T, 64M Cache (200W) DDR5-4800 |
Processor Thermal Configuration | Heatsink for 2 CPU configuration (CPU less than or equal to 240W) |
Memory Configuration Type | Performance Optimized |
Memory DIMM Type and Speed | 4800MT/s RDIMMs |
Form Factor | 1U Rack Server |
Memory | 16GB RDIMM, 4800MT/s Single Rank |
RAID | C7, Unconfigured RAID for HDDs or SSDs (Mixed Drive Types Allowed) |
RAID Internal Storage Controllers | PERC H755 with rear load Brackets |
Storage | 480GB SSD SATA Read Intensive 6Gbps 512 2.5in Hot-plug AG Drive, 1 DWPD |
BIOS and Advance System Configuration | Performance BIOS Setting |
Advance System Configuration | UEFI BIOS Boot Mode with GPT Partition |
Fans | High Performance Fan x4 |
Power Supply | Single, Hot-plug, Power Supply Non-Redundant (1+0), 1400W, Mixed Mode |
Power Cords | C13 to C14, PDU Style, 12 AMP, 6.5 Feet (2m) Power Cord, North America |
PCLe Riser | Riser Config 1, 3 x16 LP |
Motherboard | PowerEdge R6625 Motherboard |
Bezel | No Bezel for x8 and x10 Chassis |
Boot Optimized Storage Cards | No BOSS Card |
Operating System | No Operating System |
OS Media Kits | No Media Required |
Embedded Management Systems | iDRAC9, Express 16G |
Quick Sync | No Quick Sync |
Password | iDRAC,Factory Generated Password |
IDRAC Service Module | iDRAC Service Module (ISM), NOT Installed |
Group Manager | iDRAC Group Manger, Disabled |
Rack Rails | No Rack Rails or Cable Management Arm or Strain Relief Bar |
