Fortinet FortiGate 7121F 16U 12-slot chassis Firewall

FG-7121F-BDL-809-12
Item Condition : Brand New
Hurry! Other 2 people are watching this product
SKU
FOR_FRW_7121F
$455,000.00
In stock
Free shipping
could be yours in 1 - 5 days
Hurry! Other 2 people are watching this product

The FortiGate 7121F series delivers high performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high-throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage industry-leading IPS, SSL inspection, and advanced threat protection to optimize your network’s performance. Fortinet’s Security-Driven Networking approach provides tight network integration to the new security generation.

Details
FortiGate Next-Gen Firewall Overview

FortiGate: Next-Generation Firewall Overview

FortiGate next-generation firewalls (NGFWs) use purpose-built security processors and threat intelligence from FortiGuard labs to offer top-rated protection and high-performance inspection of both clear-text and encrypted traffic. NGFWs reduce complexity by offering full visibility into applications, users, and networks while integrating with the Fortinet Security Fabric and third-party solutions.

FortiGate Deployment Details

Flexible and Scalable Deployment

FortiGate NGFWs can be deployed at the network edge, core, data center, internal segment, or cloud. Purpose-built SPUs deliver scalable performance for advanced security services including threat protection and SSL inspection.

FortiGate Threat Protection

Intelligent Security Management

FortiGate offers automated visibility into cloud apps and IoT devices, continuous threat updates, and integration with Fortinet Security Fabric to share threat intelligence and enhance protection.

Key Features and Benefits

  • High-performance threat protection: Best-in-class performance with SSL inspection for encrypted traffic security.
  • Validated security effectiveness: FortiGuard updates and third-party certifications ensure robust protection.
  • Protect mission-critical applications: Ultra-low latency and scalable segmentation for secure operations.
  • Continuous risk assessment via automation: Automated workflows help manage security compliance efficiently.
  • Security Fabric integration: Real-time threat intelligence sharing across the security ecosystem.
  • Enterprise-class security management: Unified management with a single pane-of-glass across environments.
Tech Specs

Tech Specs & Customization

expert_image
Still have Questions?
Call +1 833 631 7912

Performance

  • Threat Protection Throughput: 520 Gbps
  • SSL Inspection Throughput: 540 Gbps
  • Application Control Throughput: 1.5 Tbps
  • NGFW Throughput: 550 Gbps
  • IPS Throughput: 675 Gbps

Network Interfaces

  • 10 GE SFP+/SFP, 40 GE QSFP28, 100 GE QSFP28, 400 GE QSFP28

Interfaces and Modules

  • 400 GE QSFP-DD / 100 GE QSFP28 / 40 GE QSFP+ Slots: 24
  • 100 GE QSFP28 / 40 GE QSFP+ Slots: 36
  • 100 GE QSFP28 / 40 GE QSFP+ Management/HA Slots: 4
  • 25 GE SFP28 / 10 GE SFP+ Slots: 80
  • 25 GE SFP28 / 10 GE SFP+ SFP Management/HA Slots: 4
  • GE RJ45 Management Ports: 4
  • USB Ports: 2
  • Console Ports: 14

Storage & Transceivers

  • Onboard Storage: 4x 4 TB SSD
  • Included Transceivers: 4x 10 GE SFP+ SR

System Performance & Capacity

  • IPv4/IPv6 Firewall Throughput: 1.89 / 1.88 / 1.129 Tbps
  • Firewall Latency: 7.50 μs
  • Firewall PPS: 1680 Mpps
  • Concurrent Sessions: 1 Billion
  • New Sessions/Second: 9 Million
  • Firewall Policies: 200,000

VPN Performance

  • IPSec VPN Throughput: 630 Gbps
  • Gateway-to-Gateway Tunnels: 40,000
  • Client-to-Gateway Tunnels: 260,000
  • SSL-VPN Throughput: 13.7 Gbps
  • Concurrent SSL-VPN Users: 30,000

SSL Inspection

  • SSL Throughput: 540 Gbps
  • SSL CPS: 480,000
  • SSL Concurrent Sessions: 100 Million

Virtualization & Scalability

  • Virtual Domains: 10 (Default) / 500 (Max)
  • Max FortiSwitches: 300
  • Max FortiTokens: 20,000

High Availability

  • Active-Active (FGSP), Active-Passive, Clustering

Form Factor

  • 16 RU - 10 Slots for FPM, 2 Slots for FIM

Dimensions & Power

  • Size (in): 28.63 x 17.33 x 26.6
  • Size (mm): 727.2 x 440 x 675.5
  • Weight: 447.36 lbs / 203.1 kg
  • Max Power Consumption: 9754 W
  • Avg Power: 8296 W
  • AC Current Max: 8 x 10A
  • Heat Dissipation: 33,261 BTU/h

Environment & Compliance

  • Operating Temp: 32–104°F (0–40°C)
  • Storage Temp: -31–158°F (-35–70°C)
  • Humidity: 5% to 90% non-condensing
  • Certifications: FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
