FortiGate 3500F NGFW – 72 Gbps IPS, 100GE Ports & ZTNA Firewall

Fortinet FortiGate 3500F – Hyperscale Next‑Generation Firewall with 100GE/25GE Ports & Integrated ZTNA

From

Special Price $130,995.00 Regular Price $205,000.00

Home
Fortinet FortiGate 3500F – Hyperscale Next‑Generation Firewall with 100GE/25GE Ports & Integrated ZTNA

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Sale

See all specs

Have questions about this purchase?

Chat with Uvation Assistant

Ask An Expert → +1 833 631 7912 (North America)

FG-3500F

Item Condition : Brand New

Earn 130,995 points when you buy me!

Hurry! Other 1 people are watching this product

SKU

FOR-FTG-3500F

Add a Review

Be the first to review this product

Special Price $130,995.00 Regular Price $205,000.00

In stock

Hurry! Other 1 people are watching this product

High-performance NGFW delivering 72 Gbps IPS, 65 Gbps NGFW, and 63 Gbps threat protection through SPU-accelerated architecture and built-in Zero Trust Network Access.

Details

Security-Driven Networking with FortiGate 3500F

The FortiGate 3500F Series enables organizations to build security-driven networks, forming the foundation of a robust Hybrid Mesh Firewall architecture. This approach weaves security deep into their datacenter and across their hybrid IT environment, protecting any edge at any scale.

Automated and Coordinated Threat Protection

Powered by AI/ML-based FortiGuard Services and the integrated Security Fabric platform, FortiGate 3500F delivers automated, end-to-end protection. ZTNA enforcement ensures secure and seamless access for validated users.

Enhanced Capabilities with Hyperscale License & TPM

The FortiGate 3500F features a Hyperscale Firewall License for CGNAT acceleration via Fortinet’s patented SPU NP7 and includes a Trusted Platform Module (TPM) to ensure hardware-level cryptographic security against cyber threats.

Tech Specs

Tech Specs & Customization

Still have Questions?

Call +1 833 631 7912

Network Interfaces

GE RJ45, 25 GE SFP28 / 10 GE SFP+ / GE SFP
100 GE QSFP28 / 40 GE QSFP+ Slots

Interfaces and Modules

6x 100 GE QSFP28 / 40 GE QSFP+ Slots
32x 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots
2x 10GE/GE RJ45 Management Ports
1x USB Client / 1x USB Server
1x Console Port
Included Transceivers: 2x SFP+ (SR 10 GE)
Trusted Platform Module (TPM): Yes

Performance

IPS Throughput: 72 Gbps
NGFW Throughput: 65 Gbps
Threat Protection: 63 Gbps
SSL Inspection Throughput: 63 Gbps
Firewall Throughput (Packet/sec): 630 Mpps
IPv4/IPv6 Firewall Throughput: 595 / 590 / 420 Gbps

VPN & SSL

IPsec VPN Throughput: 165 Gbps
SSL-VPN Throughput: 16 Gbps
Concurrent SSL-VPN Users: 30,000
SSL Inspection CPS: 60,000
SSL Inspection Concurrent Session: 15 Million

Sessions & Policies

Concurrent Sessions: 140M / 348M
New Sessions/sec: 1M / 5M
Firewall Policies: 200,000

Virtualization & Integrations

Virtual Domains: 10 / 500
Max FortiSwitches: 300
Max FortiAPs: 4096 / 2048
Max FortiTokens: 20,000
High Availability: Active/Active, Active/Passive, Clustering

Dimensions and Power

Size (inches): 3.5 x 17.4 x 21.9
Size (mm): 89 x 443 x 556
Weight: 43.8 lbs (19.9 kg)
Form Factor: Rack Mount, 2 RU
Power Supply: 100–240V AC, 50/60 Hz
Power Consumption: 760W / 1174W
Heat Dissipation: 4006 BTU/h
Redundant PSU: Yes (Hot Swappable)
Efficiency Rating: 80Plus Compliant

Environmental & Compliance

Operating Temp: 32–104°F (0–40°C)
Storage Temp: -31 to 158°F (-35–70°C)
Humidity: 20–90% non-condensing
Noise: 53.5 dBA
Altitude: Up to 10,000 ft (3048m)
Compliance: FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB
Certifications: ICSA Labs (Firewall, IPsec, IPS, Antivirus, SSL-VPN), USGv6/IPv6
