Juniper SRX2300 High Availability Firewall DC

Details

High-throughput firewall for next-generation protection

The SRX2300 next-generation firewall (NGFW) protects small and midsized campus, data center, and regional headquarters networks. The 1U, power-efficient device delivers up to 90 Gbps firewall throughput per rack unit and supports 100 Gbps interfaces with wire-speed MACsec encryption to safeguard data in motion.

With networking and security combined in a single platform, SRX2300 enables high-performance, low-latency defense against emerging cyber threats.

Integrated zero-trust security with fabric awareness

Zero-trust capabilities and cryptographically signed 802.1AR device identity (DevID) stored in TPM 2.0.
EVPN-VXLAN fabric integration and AI Predictive Threat Prevention for enhanced security efficacy.
Centrally managed via Juniper Security Director Cloud for unified policy and IPsec VPN control.

Juniper SRX2300 Security Director Integration

Distributed architecture and seamless transformation

Part of Juniper’s Connected Security Distributed Services Architecture for scalable and elastic security services.
First NGFW to implement EVPN type 5 and VXLAN in the data center, enabling secure fabric-aware leaf role.
Supports hybrid and multi-cloud environments while integrating with Juniper and third-party networks.

Juniper SRX2300 Hybrid Cloud Integration

AI-driven threat prevention and intelligent automation

Secure your network with built-in automation and AI-based defense capabilities:

AI Predictive Threat Prevention blocks known and zero-day threats across the full attack lifecycle.
Single-policy framework simplifies policy management across users, devices, and applications.
On-box GUI streamlines autoprovisioning, NAT, firewall policies, and IPsec VPN deployment.

Tech Specs

Tech Specs & Customization

Still have Questions?

Call +1 833 631 7912

Connectivity

Onboard ports: 8 x 1 GbE/2.5 GbE/5 GbE/10 GbE BASE-T
Onboard small form-factor pluggable plus (SFP+) transceiver ports: 8 x 1 GbE/10 GbE SFP+
2 x 1 GbE/10 GbE/25 GbE SFP28
2 x 40 GbE/100 GbE QSFP28
Out-of-Band (OOB) management ports: 1 x 1 GbE (RJ-45)
Dedicated high availability (HA) ports: 2 x 1 GbE SFP
Console: 1 (RJ-45)
USB 3.0 Ports (Type A): 1

Storage

1 x 120 GB SSD (system/logging)

Dimensions & Power

Form Factor: 1U
Size (W x H x D): 17.28 x 1.74 x 18.20 in
Weight:
- Chassis with two AC power supplies: 19 lb (8.6 kg)
- Chassis with two DC power supplies: 19.3 lb (8.8 kg)
- Chassis with package for shipping: 35.6 lb (16.2 kg)
Redundant PSU: 1+1
Power Supply:
- 2 x 450 W AC PSU redundant
- 2 x 650 W DC PSU redundant
Average Heat Dissipation:
- 1 x DC PSU (40V): 487.9 BTU/h
- 2 x DC PSU (40V): 498 BTU/h
- 1 x AC PSU (110V): 467.5 BTU/h
- 1 x AC PSU (230V): 445.3 BTU/h
- 2 x AC PSU (110V): 510 BTU/h
- 2 x AC PSU (230V): 501.6 BTU/h
Maximum Current Consumption:
- 2 A (for 110 V AC PSM)
- 1 A (for 230 V AC PSM)
- 4.7 A (for -40 V DC PSM)
Maximum Inrush Current:
- 50 A for 1 cycle of AC (AC PSM)
- 40 A-pk (DC PSM)

Environment and Regulatory Compliance

Acoustic Noise Level: 58 dB (max)
Airflow/Cooling: Front to back
Operating Temperature: 32° to 104° F (0° to 40° C at 6000 ft altitude)
Operating Humidity: 5% to 90% non-condensing
Meantime Between Failures (MTBF): Over 100,000 hours (12 years)
FCC Classification: Class A
RoHS Compliance: RoHS 6

Performance and Scale

Firewall Throughput (IMIX packet size): 26 Gbps
Firewall Throughput (1518B packet size): 39 Gbps
IPsec VPN Throughput (IMIX): 15 Gbps
IPsec VPN Throughput (1400B): 36 Gbps
Application Security Performance (TPS/CPS): 36 Gbps / 19 Gbps
Next-Generation Firewall (TPS/CPS): 35 Gbps / 10 Gbps
Secure Web Access Firewall (TPS): 9.5 Gbps
Advanced Threat (CPS): 4.5 Gbps
Connections Per Second (64B): 320,000
SSL Connections Per Second: 7,600
Max Concurrent Sessions (IPv4 or IPv6): 5 Million
Route Table Size (RIB/FIB) IPv4: 2 Million / 1 Million
IPsec VPN Tunnels: 4,000
