The Juniper SRX4600 Firewall protects mission-critical data center and campus networks for enterprises, service providers, and cloud providers. The SRX4600 is an integral part of the Juniper Connected Security portfolio, which extends security to every point on the network to safeguard users, data, and infrastructure against advanced threats.

Details

Juniper Networks® SRX4600 Firewall

The Juniper SRX4600 Firewall protects mission-critical data center and campus networks for enterprises, service providers, and cloud providers. The SRX4600 is an integral part of the Juniper Connected Security portfolio, which extends security to every point on the network to safeguard users, data, and infrastructure against advanced threats.

The SRX4600 next-generation firewall (NGFW) integrates networking and security into a single platform, delivering high-performance, scalable intrusion detection/prevention and dynamically protecting against malware. Centrally managed by Juniper Security Director Cloud software, the SRX4600 delivers IPsec VPN, fully automated SD-WAN, and easy policy management capabilities for reliable network security.

Juniper SRX4600 Networking Switch

Advanced Application Control and SD-WAN Capabilities

Advanced application identification and classification enables greater visibility, enforcement, control, and protection over network traffic, application access, and data. The firewall provides a detailed analysis of application volume and usage, fine-grained application control policies to allow or deny traffic based on dynamic application names or group names. Traffic is prioritized based on application information and context to reduce complexity across traditional, cloud, and hybrid IT networks.

The SRX4600 also delivers fully automated SD-WAN to both enterprises and service providers. Due to its high performance and scale, the SRX4600 acts as a VPN hub and terminates VPN/secure overlay connections in various SD-WAN topologies.

Juniper SRX4600 Deployment

Architecture and Key Components

The SRX4600 hardware and software architecture provides cost-effective security in a small **1 RU form factor**. Purpose built to protect network environments and provide Internet Mix (IMIX) firewall throughput of up to **400 Gbps**, the SRX4600 incorporates multiple security services and networking functions on top of Junos OS. Best-in-class security and advanced threat mitigation capabilities on the SRX4600 are offered as **33 Gbps of next-generation firewall**, **45.4 Gbps of intrusion prevention system (IPS)**, and up to **44 Gbps of IPsec VPN** in the data center, enterprise campus, and regional headquarters deployments with IMIX traffic patterns.

Juniper SRX4600 Core Aggregation

Key Features

  • Advanced Threat Prevention: Dynamic threat protection with Juniper Advanced Threat Prevention (ATP), including malware sandboxing, threat intelligence feeds, and Encrypted Traffic Insights to detect malware hidden in SSL-encrypted traffic.
  • Next-Generation Firewall: Detect and mitigate threats using software-enabled NGFW features, including an intrusion prevention system (IPS), application security (AppSecure), user identity services, and role-based access control (RBAC). For content security, the firewall supports integrated network antivirus, antispam, and enhanced web filtering capabilities.
  • Express Path Optimization: The express path optimization mechanism on SRX line cards improves throughput and lowers latency by identifying and accelerating traffic flows that don’t require deep-packet inspection.
  • EVPN-VXLAN: EVPN-VXLAN (EVPN Type 5 route) configuration supported across all Juniper SRX Series Firewalls embeds security across the entire EVPN-VXLAN fabric, everywhere your workloads are.
  • Juniper Secure Connect: Our highly flexible SSL VPN and IPsec application provides remote employees with dynamic, adaptive, and secure VPN access to your corporate and cloud resources.
Juniper SRX4600 Power Efficiency
Tech Specs

Tech Specs & Customization

expert_image
Still have Questions?
Call +1 833 631 7912

Connectivity

  • Onboard ports: Up to 24 x 1GbE/10GbE (SFP+)
  • Onboard small form-factor pluggable plus (SFP+) transceiver ports: 4 x 40GbE/100GbE (QSFP28)
  • Out-of-Band (OOB) management ports: RJ-45 (1 Gbps)
  • Dedicated high availability (HA) ports: 2 x 1 GbE SFP
  • Dedicated high availability (HA) ports: 2 x 1GbE/10GbE (SFP+) Control, 2 x 1GbE/10GbE (SFP+) Data
  • Console: 1 (RJ-45)
  • USB 2.0 ports (Type A): 1

Memory and Storage

  • System memory (RAM): 256 GB
  • Storage (SSD): 2 x 1 TB M.2 SSD

Dimensions and Power

  • Form factor: 1U
  • Size (W x H x D): 17.4 x 1.7 x 26.5 in
  • With AC PEMs: 17.4 x 1.7 x 27.29 in
  • Weight (system and 2 power entry modules):
    • With AC PEMs: 38 lb (17.24 kg)
    • Shipping weight: 45.47 lb (20.62 kg)
  • Redundant PSU: 1+1
  • Power supply: 2 x 1600 W AC PSU redundant
  • Average heat dissipation: 2218 BTU/hour
  • Average power consumption: 650 W
  • Maximum current consumption: 12 A (for 110 V AC power), 6 A (for 220 V AC power)

Precision Time Protocol Timing Ports

  • Time of day – RS-232 (EIA-23): 1 x RJ-45
  • BITS clock: 1 x RJ-48
  • 10-MHz timing connector (GNSS): 1 x Input (COAX), 1 x Output (COAX)
  • Pulse per second connection (1-PPS): 1 x Input (COAX), 1 x Output (COAX)

Environment and Regulatory Compliance

  • Acoustic noise level: 69 dBA at normal fan speed, 87 dBA at full fan speed
  • Airflow/cooling: Front to back
  • Operating temperature: 32° to 104° F (0° to 40° C at 6000 ft altitude)
  • Operating humidity: 5% to 90% non-condensing
  • Meantime between failures (MTBF): Over 111,626 hours (12.75 years)
  • FCC classification: Class A
  • RoHS compliance: RoHS 6
  • NEBS compliance: Designed for NEBS Level 3

Performance and Scale

  • Routing/firewall (64 B packet size) throughput Gbps: 104 Gbps
  • Routing/firewall (IMIX packet size) throughput Gbps: 400 Gbps
  • Routing/firewall throughput: 400 Gbps
  • IPsec VPN (IMIX packet size) throughput Gbps: 44.4 Gbps
  • IPsec VPN (1400B packet size) throughput Gbps: 69.6 Gbps
  • Application security performance in Gbps (TPS/CPS): 75.5 Gbps
  • IPS recommended in Gbps (TPS/CPS): 45.5 Gbps
  • Next-generation firewall in Gbps (TPS/CPS): 33 Gbps
  • Secure Web Access Firewall in Gbps (TPS): 22.6 Gbps
  • Advanced Threat in Gbps (CPS): 1.3 Gbps
  • Connections per second (64B): 600,000
  • Maximum security policies: 80,000
  • Maximum concurrent sessions (IPv4 or IPv6): 60 Million
  • Route table size (RIB/FIB) (IPv4): 4 Million/1.2 Million
  • IPsec VPN tunnels: 2,000
  • Number of remote access/SSL VPN (concurrent) users: 2,000
  • Max VLANs: 4,096
  • GRE Tunnels: 2,000
  • Maximum Security Zones: 512
  • Maximum Virtual Routers: 512
  • NAT Rules: 8,000
