Dell PowerSwitch Z9864F-ON High-Performance, High-Density Open Networking 800GbE Multi-Rate AI Fabric Switch

Networking for the future-ready data center

Our open networking vision embraces massive scalability along with added agility in open, disaggregated solutions. Pick and choose the hardware, software, and network operating software (and components) that best fit your requirements within your data center and at the edge.

At the same time, take advantage of automation and innovative management tools and other key integrations that streamline and simplify your experience with open networking technology.

Ultimate flexibility — from density to deployment

Dell PowerSwitch Z-series switches simplify manageability and give you the flexibility to stay ahead of data needs rather than react to them.

Optimized leaf/spine architecture with Z-series switches supports data centers of virtually any size, with up to 100,000 servers.
Exceptionally high density with Z9864F-ON providing 64 ports of 800GbE, Z9664F-ON with 64 ports of 400GbE, and Z9432F-ON with 32 ports of 400GbE.

On-demand performance

Multi-rate options including 10, 25, 40, 50, 100, 200, 400 and 800GbE.
Up to 51.2Tb/s non-blocking (half duplex) on Z9864F-ON, 25.6Tb/s on Z9664F-ON, and 12.8Tb/s throughput on Z9432F-ON.
Exceptional low latency delivering sub-microsecond performance.
User-configurable table adjustments for virtualized data-center deployments.

Energy and resource efficient

Dell PowerSwitch Z-series offers outstanding performance and is one of the most power-efficient fabric switches on the market today. The Z-series switches help reduce energy costs, speed setup and improve the bottom line with:

Up to one-third the power consumption of comparable leading switches.
Up to 7x faster deployment over traditional deployment methods.
Tool-less enterprise ReadyRails™ for fast, easy installation.

Tech Specs & Customization

Still have Questions?

Call +1 833 631 7912

Physical

64x800GbE OSFP112, 2x10GbE SFP+ ports
1 RJ45 console/management via RS232
1 USB-C for serial access console/management
1 RJ45 10/100/1000BaseT Ethernet for management
1 USB 3.0 Type A storage port

Chassis

Size: 2U, 438.5 x 630 x 87.3 mm (W x D x H), 17.26 x 24.80 x 3.43 inches (W x D x H)
Switch without PSU and Fan tray: 44.1 lbs (20 kg)
Switch with PSU and Fan trays: 55.8 lbs (25.3 kg)

Environmental – Operating

Temperature: 0°C to 45°C (32°F to 113°F)
Humidity: 8 to 90% RH, non-condensing

Environmental – Non-Operating

Storage Temperature: -40°C to 65°C (-40°F to 149°F)
Storage Humidity: 5 to 95% RH, non-condensing

Redundancy

Hot swappable redundant power (1+1)
Hot swappable redundant fans (3+1 fan modules)
Each fan module includes one dual-stacked fan

Performance

Switch Fabric Capacity: 51.2Tbps (half duplex)
Forwarding Rate: 20.3Bpps
Latency: Sub-700ns
Packet Buffer: 165.2MB (82.6MB per ITM, 2 per NPU)
NPU: Programmable pipeline with NPL
CPU: Intel® Xeon® D-1714 4-core @ 2.3GHz (3.4GHz Turbo)
Memory: 32GB DDR4 ECC

Routing & Tables

MAC addresses: 156K
ARP: 16K standalone, 8K shared
IPv4 Routes: up to 400K (ALPM)
IPv6 Routes: up to 300K
Multicast Hosts: 1K | Multicast IPv6: 4K
Layer 2 VLANs: 4K | MSTP: 64 instances
LAG: Layer 2, IPv4 or IPv6 based load balancing

Timing & Synchronization

Timing Card supports SyncE with Stratum 3E class OCXO
PTP/1588 Class C Phase performance

Security

Hardware Root of Trust
Secure Boot
TPM 2.0 Trusted Platform Module

Optics & Airflow

Up to 64 ports of 18W optics in IO/PSU airflow
Up to 32 ports of 17W optics in PSU/IO at 35°C
Up to 64 ports of DAC in PSU/IO at 45°C (no optics)

Power

Input: 100–240 VAC, 50/60 Hz | IEC60320 C20
Max Power: AC High Line 3000W | AC Low Line 1500W | DC 3200W
Max Utilized: 2848W | Typical: 1500W
Supports lowline & highline AC power modes

Regulatory Compliance

Safety: UL/CUL 62368-1, IEC/EN 62368-1, EN 60825-1/2, FDA 21 CFR 1040.10/1040.11
Emissions: AS/NZS CISPR 32 Class A, ICES-003 Class A, EN55032/55035 Class A, VCCI, FCC Part 15 Class A
Immunity: EN 300 386, EN 61000 series (ESD, Radiated, EFT, Surge, Conducted)
RoHS Compliant: Yes, EU RoHS

Certifications

US TAA Compliance Available
IPv6 Ready (Host and Router)

Warranty

1 Year Return to Depot (Constrained)
