Dell PowerSwitch N3248TE-ON 48-Port 1GbE Switch with 4x10GbE SFP+ & 2x100GbE QSFP28

Power-efficient 1GbE switching for Layer 3 distribution

The Dell PowerSwitch N3248TE-ON delivers resilient, wire-speed Layer 3 performance with integrated 10GbE and 100GbE uplinks, supporting high-traffic loads with a non-blocking architecture and redundant, hot-swappable 80PLUS Platinum power supplies.

Modernize your network with VRF support

Support for Virtual Routing and Forwarding (VRF) enables network segmentation on the same physical switch for secure and flexible network design.

Deploy at scale with performance assurance

The N3248TE-ON ensures high throughput with a data rate up to 576Gbps and forwarding rate up to 800Mpps. Benefit from a limited lifetime warranty and Dell’s enterprise-class ProSupport Infrastructure Suite for uninterrupted operations.

Consulting

Work with Dell's network consultants to optimize your infrastructure for multi-cloud demands using advanced analysis tools and industry-leading expertise.

Deployment

Rely on the Dell ProDeploy Enterprise Suite for accurate installation and configuration, freeing up your IT resources while minimizing downtime.

Support

Access Dell’s ProSupport experts 24/7 for help with complex network challenges, ensuring continuous productivity across your organization.

Tech Specs & Customization

Still have Questions?

Call +1 833 631 7912

Performance

Switch fabric capacity (full duplex): 576Gbps
Forwarding rate: 800Mpps

Power

Optional Power Supplies:
550W AC hot swappable with IO/PS airflow
550W AC hot swappable with PS/IO airflow
Power Cords:
C13 to NEMA 5-15, 3M
C13 to C14, 2M

Ports

48x RJ45 10M/100M/1G auto-sensing ports
4x 10G SFP+ ports
2x 100GbE QSFP28 stacking ports
Out-of-band management port (10/100/1000BASE-T)
USB (Type A) port
USB (Type B) console port
RJ45 console port with RS232 signaling

Dimensions & Weight

Height: 1.71" (43.44 mm)
Width: 17.09" (434.086 mm)
Depth: 15.75" (400.05 mm)

Security

RADIUS
TACACS+
802.1x

Regulatory

Australia/New Zealand: ACMA RCM Class A
Canada: ICES Class A; cUL
China: CCC Class A; NAL
Europe: CE Class A
Japan: VCCI Class A
USA: FCC Class A; NRTL UL; FDA 21 CFR 1040.10 and 1040.11
Eurasia Customs Union: EAC
Germany: GS mark
RoHS compliant
EU WEEE, EU Battery Directive, REACH
Energy: Japan JEL

Management

CLI
Web
SNMP

Other Switching

Open networking

Environmental

Power supply efficiency: 80% or better
Max. thermal output (BTU/hr): 723
Power consumption max (watts): 212
Operating temperature: 32° to 113°F (0° to 45°C)
Operating humidity: 95%
Storage temperature: –40° to 154°F (–40° to 67°C)
Storage relative humidity: 85%
