SuperServer SYS-821GE-TNHR (8U)

SuperServer SYS-821GE-TNHR (8U)

From
Special Price $235,900.00 Regular Price $293,247.40
compare favorite favorite
  • Home
  • SuperServer SYS-821GE-TNHR (8U)
SuperServer SYS-821GE-TNHR (8U)
SuperServer SYS-821GE-TNHR (8U)
SuperServer SYS-821GE-TNHR (8U)
Sale
See all specs
Have questions about this purchase?
Chat with Uvation Assistant
Rewards Banner

SuperServer SYS-821GE-TNHR (8U)

CSE-GP801TS
Item Condition : Brand New

Earn 235,900 points when you buy me!

Hurry! Other 1 people are watching this product
SKU
SPR-SVRVR-SYS-821GE-TNHR
Add a Review
Be the first to review this product
Special Price $235,900.00 Regular Price $293,247.40
In stock
Free shipping
could be yours in 1 - 5 days
favorite
Hurry! Other 1 people are watching this product

GPU: Up to 8x Intel Max 1550

Processor: 5th/4th Gen Intel Xeon

Memory: Up to 8TB DDR5

Storage: 16x NVMe, 3x SATA, 2x M.2

Network: 2x 10GbE with Intel X550-AT2

Details



Key Features

  1. 5th/4th Gen Intel®  Xeon® Scalable processor support
  2. 32 DIMM slots Up to 8TB: 32x 256 GB DRAM Memory Type: 5600MTs ECC DDR5
    • 8 PCIe Gen 5.0 X16 LP
    • 2 PCIe Gen 5.0 X16 FHHL Slots, 2 PCIe Gen 5.0 X16 FHHL Slots (optional)
  4. Flexible networking options
    • 2 M.2 NVMe for boot drive only
    • 16x 2.5" Hot-swap  NVMe drive bays (12x by default, 4x optional)
    • 3x 2.5" Hot-swap  SATA drive bays
    • Optional: 8x 2.5" Hot-swap  SATA drive bays
  6. 10 heavy duty fans with optimal fan speed control
    • Optional: 8x 3000W (4+4) Redundant Power Supplies, Titanium Level
    • 6x 3000W (4+2) Redundant Power Supplies, Titanium Level



SuperServer
SuperServer
SuperServer



Key Applications

  • High Performance Computing
  • AI/Deep Learning Training
  • Industrial Automation, Retail
  • Healthcare
  • Conversational AI
  • Business Intelligence & Analytics
  • Drug Discovery
  • Climate and Weather Modeling
  • Finance & Economics
Tech Specs

Tech Specs & Customization

expert_image
Still have Questions?
Call +1 833 631 7912

Motherboard

  • Model: Super X13DEG-OAD

Processor

  • Dual Socket E (LGA-4677)
  • 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors
  • Up to 64 cores/128 threads, with up to 320MB Cache per CPU
  • Supports up to 350W TDP CPUs (Air Cooled)

GPU

  • Max GPU Count: Up to 8 onboard GPUs
  • Supported GPUs: NVIDIA SXM: HGX H100 8-GPU (80GB), HGX H200 8-GPU (141GB)
  • CPU-GPU Interconnect: PCIe 5.0 x16
  • GPU-GPU Interconnect: NVIDIA® NVLink® with NVSwitch™

System Memory

  • 32 DIMM slots
  • Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM
  • Max Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMM
  • Memory Voltage: 1.1V

On-Board Devices

  • Chipset: Intel® C741
  • Network Connectivity:
    • 2 RJ45 10GbE with Intel® X550-AT2 (optional)
    • 2 SFP28 25GbE with Broadcom® BCM57414 (optional)
    • 2 RJ45 10GbE with Intel® X710-AT2 (optional)

Input / Output

  • 1 VGA port

System BIOS

  • AMI 32MB SPI Flash EEPROM

Management

  • SuperCloud Composer
  • Supermicro Server Manager (SSM)
  • Supermicro Update Manager (SUM)
  • Supermicro SuperDoctor® 5 (SD5)
  • Super Diagnostics Offline (SDO)
  • Supermicro Thin-Agent Service (TAS)
  • SuperServer Automation Assistant (SAA)

Security

  • Trusted Platform Module (TPM) 2.0
  • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
  • Cryptographically Signed Firmware
  • Secure Boot and Firmware Updates
  • Automatic Firmware Recovery
  • Remote Attestation and Runtime BMC Protections
  • System Lockdown

PC Health Monitoring

  • Monitors CPU Cores, Chipset Voltages, Memory
  • 8+4 Phase-switching voltage regulator
  • Fans with tachometer monitoring and speed control
  • Pulse Width Modulated (PWM) fan connectors
  • Temperature monitoring for CPU and chassis

Chassis

  • Form Factor: 8U Rackmount
  • Model: CSE-GP801TS
  • Height: 14" (355.6 mm)
  • Width: 17.2" (437 mm)
  • Depth: 33.2" (843.28 mm)
  • Weight: 166 lbs (75.3 kg)
  • Color: Black front & silver body

Front Panel

  • Hard drive activity LED
  • Network activity LEDs
  • Power status LED
  • System Overheat & Power Fail LED
  • Power On/Off and System Reset buttons

Expansion Slots

  • 8 PCIe 5.0 x16 LP slots
  • 2 PCIe 5.0 x16 FHHL slots

Drive Bays / Storage

  • 12 front hot-swap 2.5" NVMe drive bays
  • 3 front hot-swap 2.5" SATA drive bays
  • 2 M.2 NVMe slots (M-key)

System Cooling

  • 10 heavy duty fans with optimal fan speed control

Power Supply

  • 6x 3000W Redundant (3 + 3) Titanium Level (96%) power supplies
  • AC Input: 240Vdc / 50-60Hz
  • Dimension: 106.5 x 82.1 x 245.5 mm

Operating Environment

  • Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
  • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Operating Relative Humidity: 8% to 90% (non-condensing)
  • Non-operating Relative Humidity: 5% to 95% (non-condensing)
