Juniper EX4100-F

MFG.PART: EX4100-F-12P
Item Condition : Brand New

Earn 2,171 points when you buy me!

Hurry! Other 2 people are watching this product
SKU
EX4100-F
Add a Review
Be the first to review this product
Special Price $2,171.99 Regular Price $4,396.00
In stock
Free shipping
could be yours in 1 - 5 days
favorite
Hurry! Other 2 people are watching this product

Designed for branch deployments, the EX4100-F Ethernet Switches delivers a high-performance, cost-effective solution. With a -12 port fan-less compact, -24 port and -48 port in 1U, the EX4100-F is AI-driven, cloud-ready access switching platform. It’s differentiated by features such as EVPN-VXLAN, micro-segmentation using group-based policies (GBP), Power over Ethernet (PoE+) and flow-based telemetry.

Additionally, EX4100-F-12P (compact and fan-less) can be powered by an external Power Sourcing Equipment (PSE) as well as provide Power over Ethernet out to connected Powered Devices (PDs).

Details

The Juniper Networks® EX4100-F line of Switches offers a secure, cloud-ready portfolio of access switches ideal for enterprise branch, remote office, and enterprise campus networks. The EX4100-F switches combine the simplicity of the cloud, the power of Mist AI™, and a robust hardware foundation with high performance to deliver a differentiated approach to access switching in the cloud, mobile, and IoT era. With Juniper® Mist™ Wired Assurance, the EX4100-F line of Switches can be effortlessly onboarded, configured, and managed from the cloud. This simplifies operations, improves visibility, and ensures a much better experience for connected devices.

Key features of the EX4100-F include:

-Cloud-ready, driven by Mist AI with Juniper Mist Wired Assurance and Marvis Virtual Network Assistant
-Ethernet VPN–Virtual Extensible LAN (EVPN-VXLAN) to the access layer
-Standards-based microsegmentation using group-based policies (GBPs)
-Flow-based telemetry to monitor traffic flows for anomaly detection, ability to measure packet delays and report drop reasons

Offering a full suite of Layer 2 and Layer 3 capabilities, the EX4100-F enables multiple deployments. As scaling requirements increase, Juniper’s Virtual Chassis technology allows up to 10 EX4100-F switches to be seamlessly interconnected and managed as a single device, delivering a scalable, pay-as-you-grow solution for expanding network environments.

EX4100-F
EX4100-F
EX4100-F

The EX4100-F line consists of the following models:

-The EX4100-F-12T, which is a compact, fanless switch offering 12 x 1GbE non-PoE access ports.
-The EX4100-F-12P, which is a compact, fanless switch offering 12 x 1GbE Power over Ethernet Plus (PoE+) access ports and delivering up to 30 W per port with a total of 180 W of PoE power budget with an external power adapter. EX4100-F-12P can also be powered from an external 90 W power sourcing equipment (PSE) device connected via the uplink port. Additional 90 W of PoE budget is available if the second uplink port is connected to a PSE device. With external power adapter and the two uplink ports connected to 90 W external PSE, total PoE power budget supported is up to 300 W.
-The EX4100-F-24T, which offers 24 x 1GbE non-PoE access ports.
-The EX4100-F-24P, which offers 24 x 1GbE PoE+ access ports, delivering up to 30 W per port with an overall total 370 W of PoE power budget.
-The EX4100-F-48T, which offers 48 x 1GbE non-PoE access ports.
-The EX4100-F-48P, which offers 48 x 1GbE PoE+ access ports and delivers up to 30 W per port with an overall total PoE Power budget of 740 W.

Each EX4100-F -24 port and -48 port model offers a fixed power supply and 4 x 1GbE/10GbE small form-factor pluggable plus transceiver (SFP+ transceiver) fixed uplink ports. Each EX4100-F-12 port model offers 2 x 10GbE fixed copper uplink ports. The EX4100-F switches include 4 x 1GbE/10GbE SFP+ ports to support Virtual Chassis connections, which can be reconfigured for use as Ethernet ports for uplink connectivity. EX4100-F switch models offer standards-based 802.3af/at (PoE/PoE+) for delivering up to 30 watts on any access port. The EX4100-F switches can be configured to deliver Fast PoE capability and Perpetual PoE capability.

Tech Specs

Tech specs

Physical Specifications

Backplane80 Gbps Virtual Chassis interconnect to combine up to 10 units as a single logical device

Power Options

Power SuppliesAutosensing; 100-120 V/200-240 V; 150 W, 920 W AC AFO, and 150 W AC AFI dual load sharing hot-swappable internal redundant power supplies
Maximum Current Inrush30 amps
DC power supply150 W DC AFO; input voltage range 48-60 V max; dual load-sharing hot-swappable internal redundant power supplies
Minimum number of PSUs required for fully loaded chassis1 per switch


Dimensions

Height1 U

Environmental Ranges

Storage temperature-40° to 158° F (-40° to 70° C)
Operating altitudeUp to 5000 ft at 40° C (1828.8 m)
Nonoperating altitudeup to 16,000 ft (4,877 m)
Relative humidity operating5% to 90% (noncondensing)
Relative humidity non-operating0% to 90% (noncondensing)



Hardware Specifications

Switching Engine ModeStore and forward

Ports

Number of ports12
Rack Unit 1U


CPU

CPU 1.7 GHz ARM CPU


Security

MAC Limiting (per port and per VLAN)Supported
Allowed MAC Addresses64,000
Dynamic ARP Inspection (DAI)Supported
IP Source GuardSupported
Local Proxy ARPSupported
Static ARP SupportSupported
DHCP SnoopingSupported
Captive PortalSupported
Persistent MAC Address ConfigurationsSupported
DDoS Protection (CPU Control Path Flooding)Supported


Models
