Aruba 6300M 48-port HPE Smart Rate 1/2.5/5GbE Class 6 PoE and 4-port SFP56 Switch (JL659A)

Aruba 6300M 48-port Smart Rate 1/2.5/5GbE Class 6 PoE & 4-port SFP56 Managed Switch (JL659A)

From

Special Price $13,174.15 Regular Price $18,979.00

Home
Aruba 6300M 48-port Smart Rate 1/2.5/5GbE Class 6 PoE & 4-port SFP56 Managed Switch (JL659A)

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Sale

See all specs

Have questions about this purchase?

Chat with Uvation Assistant

Ask An Expert → +1 833 631 7912 (North America)

JL659A

Item Condition : Brand New

Earn 13,174 points when you buy me!

Hurry! Other 1 people are watching this product

SKU

A6300M-48P-CL6POE-JL659A

Add a Review

Be the first to review this product

Special Price $13,174.15 Regular Price $18,979.00

In stock

Hurry! Other 1 people are watching this product

The Aruba 6300M JL659A is a next-generation Layer 3 managed switch featuring 48 Smart Rate 1/2.5/5GbE Class 6 PoE ports and 4 high-speed SFP56 uplink ports. Designed for high-performance access, aggregation, and enterprise deployments with advanced network automation and security features.

Details

High Performance and Power

The HPE Aruba Networking CX 6300 Switch Series features a fully distributed Gen7 ASIC architecture delivering low latency, enhanced packet buffering, and adaptive power use. With wire-speed switching/routing and uplinks supporting up to 100 GbE, it supports 200–400 Gbps stacking throughput.

Smart Rate multi-gig Ethernet ports (1G/2.5G/5G/10G) with Class 4/6/8 PoE provide up to 2880W, enabling high-performance connectivity for access points and IoT. Layer 2 CX 6300L variants offer scalable, cost-effective options with static routing and stackable design.

Automation and Analytics

Gain real-time visibility with built-in analytics and a Time Series Database. The Aruba Network Analytics Engine (NAE) identifies and addresses system, network, and security issues via CLI, Python, or REST API.

AI insights in Aruba Central and Multi-Edit Software help automate configuration, ensure policy compliance, and simplify change deployment. The CX Mobile App enables one-touch stacking and import for continuous conformance validation.

Unified Management and Smarter Segmentation

Aruba CX 6300 is centrally managed via Aruba Central, offering AI tools and unified control. Dynamic Segmentation enforces identity-aware policies for users, devices, and apps across wired and wireless networks.

Advanced features include Layer 7 firewall, role-based access control, application recognition, and VXLAN to VRF mapping. Colorless ports and LMA reduce manual operations and speed up network changes.

HPE Aruba Data Center Networking Solution

Integrate CX 6300 switches with HPE’s broad IT infrastructure ecosystem, including HPE ProLiant, Nimble, Synergy, and GreenLake. These switches are ideal for complex data center environments and support deployment in HCI, SAP HANA, VMware, and HPC solutions.

Pre-engineered, ready-to-deploy configurations reduce setup time, risks, and costs while enhancing IT service delivery. Use the R9FXXX tracking SKUs for integrated deployments.

Tech Specs

Tech Specs & Customization

Still have Questions?

Call +1 833 631 7912

Power Consumption

With JL086A PSU: Idle: 133W, 100% Traffic Rate: 199W
With JL087A PSU: Idle: 138W, 100% Traffic Rate: 193W
With JL670A PSU: Idle: 140W, 100% Traffic Rate: 201W

Input Voltage

JL670A PSU: 110V‑120V/208V‑240V
JL086A PSU: 100V‑240V
JL087A PSU: 110V‑240V

Ports

48-port Smart Rate 100M**/1G/2.5G/5G BaseT Class 6 PoE ports (up to 60W per port)
4x 1G/10G/25G*/50G SFP ports
Supports IEEE 802.3af, 802.3at, and 802.3bt
1x USB‑C Console Port
1x OOBM port
1x USB Type A Host port

Notes: *50G capability is for use with DACs; **100M full‑duplex only.

Latency

1Gbps: 4.24μSec
10Gbps: 1.50μSec
25Gbps: 2.91μSec
50Gbps: 3.49μSec

Switching Capacity

880 Gbps

Stacking Capabilities

Up to 10 switches per stack
NOTE: CX 6300L switches only stack with other CX 6300L switches

Throughput

654 Mpps

Memory and Processor

Quad Core Arm Cortex™ A72 @ 1.8GHz
8 GB DDR4, 32 GB eMMC
8/16/32 MB Shared Packet Buffer Memory

PoE Capability

Max PoE Power: 2880W

Management Features

HPE Aruba Networking Central Network Management
AirWave Management Software
Switch Multi-Edit Software
Command-line interface
SNMP v2c/v3
RMON

Warranty

Limited lifetime warranty

Detailed Product Description

CX 6300M 48-port HPE Smart Rate 1/2.5/5 GbE Class 6 PoE and 4-port SFP56 switch
PSU Min1 / Max2 (680W JL086A, 1050W JL087A, 1600W JL670A, 1050W JL758A) Mix OK
Includes 2x fan trays (JL669B)
Min=0 / Max=4 SFP/SFP+/SFP28/SFP56 1/10/25/50G Transceiver
1U Height

Weight

6.02 kg (13.27 lbs)

Dimensions

4.4 x 44.2 x 38.5 cm (1.73 x 17.4 x 15.2 in)
