Juniper's Connected Security Distributed Services Architecture, managed by Juniper Security Director Cloud, offers a high-performance, scalable, and easy-to-manage firewall solution to secure today’s distributed data centers.

Details

Next-Generation Firewall for Scalable Edge and Data Center Security

The Juniper Networks® SRX1600 Firewall is a high-performance, power-efficient 1U next-generation firewall (NGFW) built for enterprise campuses and midsize data centers. Delivering up to 24 Gbps firewall throughput per rack unit and support for 25 Gbps interfaces with wire-speed MACsec, it secures critical data in motion with robust encryption and performance.

With integrated zero-trust capabilities, EVPN-VXLAN fabric support, AI Predictive Threat Prevention, and centralized management via Juniper Security Director Cloud, the SRX1600 ensures end-to-end security and control across your enterprise environment.

Juniper SRX1600 Firewall

Security, Visibility, and Centralized Control

  • Zero-trust security foundation with integrated intrusion prevention, application visibility, and content filtering.
  • Managed by Juniper Security Director Cloud for unified visibility, policy configuration, and threat intelligence.
  • High port density supports secure connectivity for branch, campus, and data center deployments.
Juniper SRX1600 Deployment

Optimized Hardware and Software Architecture

  • Compact 1U form factor with scalable security features for edge and hybrid deployments.
  • Offers up to 21 Gbps NGFW, 21 Gbps IPS, and 5.5 Gbps IPsec VPN with IMIX traffic.
  • Built on Junos® OS for secure, carrier-grade performance and extensive automation capabilities.
Juniper SRX1600 Architecture

Integrated with Juniper’s Connected Security Architecture

The SRX1600 enables horizontal scalability and simplified security across on-premises and cloud environments:

  • Supports EVPN-VXLAN for fabric-aware deployment in spine-leaf architectures.
  • Facilitates SD-WAN large branch and secure hub use cases.
  • Delivers a consistent policy framework across distributed network infrastructure.
Juniper SRX1600 Security Cloud Integration
Tech Specs

Tech Specs & Customization

expert_image
Still have Questions?
Call +1 833 631 7912

Connectivity

  • 16 x 1 GbE 10/100/1000 BASE-T
  • 4 x 1 GbE/10 GbE SFP+
  • 2 x 1 GbE/10 GbE/25 GbE SFP28
  • 1 x 1 GbE RJ-45 Out-of-Band (OOB) management port
  • 2 x 1 GbE SFP dedicated high availability (HA) ports
  • 1 x RJ-45 console port
  • 1 x USB 3.0 Type-A port

Storage

  • 1 x 120 GB SSD (system/logging)

Form Factor

  • 1U

Dimensions & Weight

  • Size (W x H x D): 17.28 x 1.74 x 18.20 in
  • Weight (device + PSU): 15.7 lb (7.1 kg)
  • Shipping weight: 32.8 lb (14.9 kg)

Power Supply

  • 2 x 450 W AC PSU (redundant)
  • Redundancy: 1+1

Heat Dissipation

  • 1 x AC PSU (110V): 467.5 BTU/h
  • 1 x AC PSU (230V): 445.3 BTU/h
  • 2 x AC PSU (110V): 510 BTU/h
  • 2 x AC PSU (230V): 501.6 BTU/h

Power Consumption

  • Maximum current: 2 A (110 V AC), 1 A (230 V AC)
  • 4.7 A (–40 V DC PSM)
  • Inrush current: 50 A (AC PSM), 40 A-pk (DC PSM)

Environmental

  • Acoustic noise: 58 dB max
  • Cooling: Front-to-back airflow
  • Operating temp: 32° to 104°F (0° to 40°C at 6000 ft)
  • Humidity: 5% to 90% non-condensing
  • MTBF: Over 100,000 hours (12 years)

Regulatory

  • FCC classification: Class A
  • RoHS compliance: RoHS 6

Performance & Scale

  • Firewall (IMIX): 9 Gbps
  • Firewall (1518B): 24 Gbps
  • IPsec VPN (IMIX): 5.5 Gbps
  • IPsec VPN (1400B): 18 Gbps
  • Application security: 21.5 Gbps / 5.3 Gbps
  • IPS: 21 Gbps / 2.75 Gbps
  • NGFW: 21 Gbps / 2.75 Gbps
  • Secure Web Access FW: 2.5 Gbps
  • Advanced Threat: 1.3 Gbps
  • Connections per second: 95,000
  • Security policies: 16,000
  • Concurrent sessions: 2 Million
  • Route table size (RIB/FIB): 2M / 1M
  • IPsec VPN tunnels: 2,000
  • SSL VPN users: 2,000
  • Max VLANs: 4,096
  • GRE Tunnels: 2,000
  • Security Zones: 512
  • Virtual Routers: 512
  • NAT Rules: 8,000
